COMPACT THREADING MACHINE FLARE.4C

Heavy-duty performance with 1500W induction motor; Threads 1/4″-3/4″ at 36 RPM,. 1-2″ at 20 RPM, 2-1/2-4″ at 1l RPM. Easy transport with MH1500 stand CE standards. Available in UAE

Description

CAPACITYPipe: 1/4″ -4″(6MM-100MM} Bolt: 12MM-45MM
MOTOR1500W induction, 50 OR 60Hz SINGLE PHASE
SWITCHHeavy-duty rotary Forward/off/reverse and integral foot switch
SPINDLE SPEED36/20/11RPM.
FRONT CHUCKHammer type with replaceable rocker action jaw inserts.
REMARKSRear Centering Device: Cam action.
Oiling System: Through the die head, with integral oil reservoir.
STANDARD SUPPLYModel FLARE.4C Threading Machine. (110 or 220V )
Self-opening die head-SDHN71/SDHB91 { BSPT or NPT )
1/4-2″ Self-opening Diehead-SDHN74/SDHB94 (BSPT or NPT)
2-1/2-4″ Yi”-%” universal HSS dies set. (BSPT or NPT)
1″-2″ universal HSS dies set. ( BSPT or NPT}
 2-1/2″-4″ HS Die set. (BSPT or NPT)
Cutter-MHC2032 : Capacity: 1/4″-4″(6mm-100mm) PIPE
Reamer-MHR1010 : Positive-locking,5-flute cone, righthand 1/4″-4″(6mm-100mm).
* 1Ga llon ‘Power Fluid PF-9835’ cutting oil.
Supplied with MFS642 foot switch, MHlSOO wheel stand (Optional)
